We were asked to visit site to investigate upgrading the reverse jet pulse cleaning system for the existing fabric filter which serves the furnace. We informed the site that whilst we think that this will help with the high dP and pulse cleaning of the bags we feel that this isn’t the permanent solution to […]
We were originally contacted via a third party who were putting together a FEED study for an upgrade for a clinical waste incineration based at the Derriford hospital in Plymouth. The main order then subsequently came from Brothwell & Irvine who were the principal contractor who were overseeing the upgrades to the facility. The specification […]
Read More… from Project BI – CleaNOx Selective Non-Catalytic Reduction (SNCR) System
AT A GLANCE: 304L Stainless Circular Filter with 50mm thick insulation with a stainless-steel outer skin Outer shell surfaces to have 2B mill finish, welds ground smooth, strip polish appearance. Internal welds ground smooth and all internal surfaces polished to 0.6Ra. ATEX rated with explosion panel and ducting. CFD Modelling for design for non-deformation at […]
AT A GLANCE: SNCR System 10,000 litre Urea/Adblue bunded storage tank 4 x Ceramic coated Stainless Steel injection lances 4 x 4-20mA peristaltic dosing pumps 4kW high pressure lance cooling air fan 880L Stainless Steel bunded mixing tank Comms over ethernet control panel with HMI PROJECT MANAGER’S REPORT: In the constant pursuit of a cleaner, […]
AT A GLANCE: SNCR System 10,000 litre Water bunded storage tank 6,000 litre Urea/Adblue bunded storage tank 3 x Ceramic coated Stainless Steel injection lances 3 x 4-20mA peristaltic dosing pumps 4kW high pressure lance cooling air fan 880L Stainless Steel bunded mixing tank 1.2m³/hr duplex water softener Comms over ethernet control panel with HMI […]
AT A GLANCE: Design / Consultancy to improve ducting design and dust levels Improved extraction Re-routed ducting to allow easier maintenance and access CONSULTANT’S REPORT: We were contacted via the Engineering manager as he had been told about some previous projects we had completed for some other sites. The site had been having some issues […]
CONSULTANT’S REPORT Nitrogen Extraction System Details: Control panel ID fan Nitrogen extraction points Ducting Three nitrogen extraction points The enquiry came from a test laboratory at Sheffield Forgemasters. We had previously worked at this site on more than one occasion supplying a retractable burning booth initially and later a dedicated CleanPULSE cartridge filter for the […]
Read More… from Project SFEL – Nitrogen fumes extraction system
cleanNOx Panel Details: Project The enquiry came from a boiler consultant we had previously worked with on a flue gas treatment plant project (see project DH) which also had a SNCR system installed. Our client installed a waste heat boiler to provide a heating system to a well-known luxury yacht manufacturer factory. This enabled them […]
Read More… from Project SS (ACE) – Urea IBC system / cleanNOx Urea Skid
The original enquiry was to come to site and take some volumetric readings and to measure up to replace the lime reactor tower which was part of a waste incineration plant at Hillingdon hospital. The plant had been recently taken over and was being refurbished as the plant was in quite a poor condition. Our […]
Read More… from Project SRCL HH – GSA (Gas Suspension Absorber) Reactor Tower
CONSULTANT’S REPORT The previous owners of the plant consulted us back in 2012 to look at replacing the ducting for a cement mill which subsequently didn’t go ahead. After the plant was taken over this project was re-visited but rather than use the existing drawings, the customer wanted a neater design which was easier to […]
An empty warehouse is always a welcome place to start a project. This is because we have a blank canvas with which to design an ideal layout for a flue gas treatment plant. Once installed, our system cleans the gases from a waste boiler and waste infeed plant and will allow the end user to stop transporting waste around the country and manage it locally, save on transport costs and produce some electricity too.
